OMNIA

Watch this OMNIA overview

Product Features

MYAH Features

4-in-1 Maximized
Workflow Efficiency

One-Touch Fully Automated Interface
Reduced Training Time

Advanced Rotary Prism Technology
Stable Measurements

Compact Design
Space Optimization

Multiple Data Connectivity Options
Including DICOM

Optimize Your Clinical Workflow with Fast and Comfortable Exams

Gain unmatched flexibility with a fully automated user interface and 360° touch screen rotation. Optimize space, enhance efficiency, reduce training time, and ensure easy data capture, even for new users.

Super Luminescent Diode (SLD)¹

OMNIA uses a brighter light source to deliver clearer and higher-quality imaging than a standard LED, improving the success rate of measurements even in challenging conditions caused by media opacities.

1: Available in REF/KRT measurements mode

Multiple Connectivity Options

OMNIA can send examination data to CV-5000 and IMAGEnet^® via a shared folder. Connecting to a DICOM server makes it possible to receive a DICOM worklist, making OMNIA compatible with various network environments.

Key Features

ONE-TOUCH FULLY AUTOMATED USER INTERFACE: Enhances workflow efficiency, reduces training time, and provides reliable data that can be captured even by the newest user.
SOFTER AND QUIETER AIR PUFF: Enhanced patient comfort for a smoother intraocular pressure measurement.
ADVANCED ROTARY PRISM TECHNOLOGY: With Topcon’s Rotary Prism technology, OMNIA provides stable measurements. The unique, eccentric rotation of the measurement ring is designed to reduce artifact from the fundus.

Ready to learn more?

Contact us today

Product Specifications

REF MEASUREMENT
Measurement range	Spherical refractive power: -25D to +22D (display value resolution: 0.12D or 0.25D) Astigmatic refractive power: 0D to ±10D (display value resolution: 0.12D or 0.25D) Direction of astigmatic axis: 0° to 180° (display value resolution : 1° or 5°) (where spherical refractive power + astigmatic refractive power ≤ +22D, or spherical refractive power + astigmatic refractive power ≥-25D) The dioptric powers are indicated with reference wavelength λd = 587.56nm.
Measurable minimum pupil diameter	φ2.0mm
KRT MEASUREMENT
Measuring range	Corneal curvature radius: 5.00mm to 10.00mm (display value resolution: 0.01mm) Corneal refractive power: 67.50D to 33.75D (display value resolution: 0.12D or 0.25D) (where corneal refractive power = 1.3375 ) Direction of corneal principal meridian: 0° to 180° (display value resolution: 1° or 5°)
CORNEAL DIAMETER MEASUREMENT
Measuring range	2.00mm to 14.00 mm (display value resolution: 0.25mm)
INTRAOCULAR PRESSURE MEASUREMENT
Measuring range	7mmHg to 60mmHg (display value resolution: 1mmHg) (average value resolution: 1mmHg or 0.1mmHg)
Measuring mode	7mmHg to 30mmHg or 30mmHg to 60mmHg (selectable range)
CORNEAL THICKNESS MANAGEMENT
Measuring range	0.400mm to 0.730mm (display value resolution: 0.001mm)
OTHER SPECIFICATIONS
Electric rating	Source voltage: 100-240V AC Frequency: 50-60Hz Power input: 80VA
Dimensions and weight	Dimensions : 13-16.6in (332-422mm) (W) x 22.4-25.9in (569-658mm) (D) x 20-29.9in (504-760mm) (H) Weight : 51lb (23.2kg)
